AFLAS is a thermoplastic fluoroelastomer (TPFE) material that is often used in the manufacturing of O-rings. It is known for its excellent chemical resistance, high temperature tolerance, and low compression set. AFLAS is also resistant to a wide range of chemicals, including fuels, oils, acids, and solvents. Additionally, it has a low coefficient of friction and excellent electrical insulation properties. Due to these properties, AFLAS O-rings are commonly used in applications such as automotive, aerospace, and chemical processing industries.
Quick Specifications
| Material Code | A80 |
| Temperature Range | 25ºF up to 450ºF (-4ºC up to 260ºC) |
| Color | Black |
| Durometer (Hardness) | 80 ± 5 |
| Profile | Round |
| Tensile Strength (psi) | 3625 - 4496 |
| Elongation Change % (minimum) | 300 - 400 |
| Shelf Life | Unlimited |
| Industry Names | Aflas® |
