APG 0759IG3 - Medium Density Black Nitrile Wide Extruded Closed Cell Sponge

December 15, 2022

APG 0759IG3 Medium Density Black Nitrile Wide Extruded Closed Cell Sponge is a versatile and durable material that is suitable for a wide range of applications. Its tiny, sealed cells contain inert nitrogen gas, which helps to resist moisture and maintain its shape and structure. This makes it an excellent choice for use in wet or moist enclosures. In addition to its resistance to moisture, black nitrile closed cell sponge also has excellent sound and vibration dampening properties. It can be used to reduce noise and vibration in a variety of applications.

Product Specifications

Properties	Typical Values
Color	Black
Firmness	Medium
Cell Type	Closed Cell
Backing Type	Plain
Temperature Range	-40ºF up to 200ºF
Brittle Point	-40ºF
25% Compression Deflection	5-9 psi
25% Compression Resistance	5-11 psi
50% Compression Set	25 (Maximum)
Density, lb/ft³ (3/8” & higher)	6-10
Density, lb/ft³ (1/4” & lower)	6-12
Water Absorption, lb/ft²	0.1 (Maximum)
Tensile Strength (Typical)	75 psi (Minimum)
Enlongation % (Typical)	100% (Minimum)
Flammability (FM VSS No. 302 \| ASTN D 6576)	Pass
Ozone Resistance (GM4486P)	Pass (No Cracking)
